Used Groundsmaster® 3500-D

$29,990.00

*Excluding GST & prices starting from. All prices in AUD.*

  • ✅ Fully Serviced
  • ✅ Professionally Cleaned
  • ✅ Warranty Available
  • ✅ Delivery Australia Wide

📞 Chris Paterson – PH- 0418755697

📞 Danny Foott – PH – 0487962042

📞 Freecall  – 1800 704 574

✉️ Email – chris@golfmowersaustralia.com.au

✉️ Email – sales@golfmowersaustralia.com.au

⛳ Call NOW for over the phone deals !

SKU: Toro Groundsmaster 3500 - D Used - Australia GM - 3500 - D -1-2 Categories: , ,
Description



  • The Contour™ Plus cutting technology takes quality of cut to a whole new level
  • Sidewinder cutting units shift left and right a total of 61 cm
  • The unique Toro Series/Parallel™ traction drive system provides steady traction in all conditions

The Groundsmaster® 3500-D is a revolutionary triplex rotary mower designed for superior performance trimming. The free-floating Contour™ Plus cutting decks allow mowing of undulating terrain without scalping. The powerful 18.5 kw Kubota® engine and exclusive Series/Parallel™ traction drive system, gets the mowing job done quickly.

Sidewinder® Cutting Unit System

Sidewinder cutting units shift left and right a total of 61 cm. This allows the tyre tracks to be shifted within the mowing path to reduce wear on the turf.

Time Saving

Unlike any other mower on the market, the Groundsmaster® 3500-D allows you to be more productive. The 68″ (173 cm) width-of-cut allows you to mow generous swaths, yet its compact size and the Sidewinder® system also allow you to make tight maneuvers in trim areas. Locations normally requiring two different machines can be handled by one.

Quality of Cut

The new Contour™ Plus cutting technology takes quality of cut to a whole new level. Air inlet pockets keep the grass standing tall for the cleanest possible cut, while an acceleration baffle speeds clipping circulation and assures maximum power. In addition, a unique directional vane and modified discharge opening deliver even clipping dispersion. An optional mulching kit is also available.

Scalp-Free Mowing

The ground-following design of each Contour™ Plus free-floating deck permits mowing the most challenging berms without scalping. Two front rollers and a rear roller allow the deck to smoothly pass over turf.

Attractive Striping

Rear rollers provide an attractive striping effect while you mow, greatly enhancing the finished look of your turf.

Superior Traction

The patented Toro Series/Parallel™ traction drive system provides steady traction in all conditions, even in wet grass and over undulating terrain. Its full-time, 3-wheel drive system maintains power to two of the three wheels at all times, minimising tyre spinouts and scuffing.

Engine Kubota® 3-cylinder, liquid-cooled diesel
Engine Power (kW) 25 hp (18.5 kW)
Fuel Type Diesel
Fuel Capacity 41.6 litres
Cooling System Rear-mounted, cross flow 4-row radiator
Air Filter Remote-mounted 5″ Donaldson® air cleaner
Cutting Width 173 cm (68″) standard and 183 cm (72″) optional.
Mowing Rate 1.7 hectares/hr
Deck Design 10-gauge steel constructed chambers with 12-gauge welded reinforcements. 1.5″ (3.8 cm) square x 0.25″ (0.6 cm) wall tube with 7-gauge side supports. Spindle support 3/16″ (0.48 cm) high-strength steel and 10-gauge exterior channels
Blades Combination Blades: 27″ (68.6 cm) long, 2.5″ (6.4 cm) wide, 0.25″ (0.64 cm) thick
Spindle Housing Ductile cast iron spindle housing
Spindle Bearings Dual greaseable tapered roller bearings. 3.2 cm diameter solid cold finished steel spindle shaft
Height of Cut 0.75″ – 4″ (1.9 cm – 10.2 cm) in 0.25″ (0.6 cm) increments. 3-position 0.030″ (0.08 cm) incremental calibration
Armrests Standard
Ground Speed – Forward 0-14 km/h
Mowing Speed 0-10 km/h
Traction Drive (System) 3-wheel drive hydrostatic series/parallel closed-loop transmission
Controls Forward and reverse traction control pedals; mow/transport foot lever; hand activated parking brake; hand operated ignition key switch; tilt steering wheel lock; PTO switch; throttle; joystick control for deck raise and lower; cutting deck transport lock
Steering Controls Hydraulic power steering, tilt wheel
Tyres 20″ X 10″-10″, 4-ply rating, Toro Turf Tread Rear tyres. 20″ X 12″-10″, 4-ply rating, Toro Turf Tread Front tyres
Seat Two-piece premium commercial two-tone grey vinyl with two armrests, fore/aft adjustment
Ground Clearance 15.3 cm
Assembled Width Metric 184 cm
Assembled Height Metric 193 cm
Weight 957 kg

*Please note used machines may vary from the specifications of a brand new machine. Descriptions are a guide only.
